Comparing Energy and Power Performance of Diverse Energy Storage Technologies
Energy Density vs Power Density Graph
This diagram effectively compares various energy storage technologies based on their energy density and power density. On one end, fuel cells offer high energy storage capacity with lower power output. On the other, conventional capacitors provide rapid power delivery but store less energy. Conventional batteries sit in a middle ground, offering a balanced performance, while ultracapacitors bridge the gap, providing a good blend of both energy and power capabilities.
