Gear and Rack Mechanism Illustration

A technical illustration showcasing a classic gear and rack mechanism, demonstrating how rotational motion of a gear can be converted into linear motion along a toothed rack. The brown textured components feature interlocking teeth, with blue directional arrows indicating movement and rotation.

mechanics - engineering - motion - gears - transmission - machine - kinematic - design - prototype
