Grey Water Recycling System Diagram
Understanding a Typical Home Grey Water Recycling System Setup for Sustainable Living

Grey Water Recycling System Diagram

This diagram illustrates the flow of a typical ultraGTS grey water recycling system within a residential setting. It shows how water from showers, vanity basins, baths, and laundry facilities is collected, treated through an ultraGTS unit, and stored in a re-use tank. The treated greywater is then repurposed for non-potable uses like flushing toilets and outdoor irrigation, with an overflow connection to the sewer for excess water. The system promotes water conservation by diverting used water from a household for secondary uses.

greywater - water recycling - sustainable home - plumbing diagram - water conservation - reclamation
