RV Floor Plan Layout Illustration

This image displays a comprehensive overhead view of an RV's interior layout, showcasing a well-organized living space. The design includes a rear bedroom with a queen bed, nightstands, and wardrobes, a mid-ship bathroom with a toilet and shower, a kitchen area equipped with a fridge, microwave, pantry, and linen storage, and a front living space featuring a theater sofa, a cockpit with a table, and a 40-inch TV. Various 'S' symbols indicate slide-out sections, designed to expand the interior space when parked. This illustration provides a clear understanding of the RV's functional zones and spatial arrangement.

rv - floorplan - motorhome - layout - interior - diagram - design
