Compton Scattering Diagram in Physics

Here's a clear diagram depicting Compton scattering, a key concept in quantum physics. It shows an incoming photon (represented by the blue wave labeled hν) interacting with an electron (the blue 'e'). Following the interaction, the photon emerges with less energy (the red wave labeled hν'), meaning its wavelength has increased, and the electron recoils, now labeled e', having gained kinetic energy. This visual helps explain how light behaves as particles and how energy and momentum are conserved during such collisions.
